TOHO TECH0103 1 Tonne 3m Electric Chain Hoist Single Phase

TOHO TECH0103 1 Tonne 3m Electric Chain Hoist Single Phase

SKU: TECH0103
On backorder
$2,400
Or
4 payments of $600 with
  • Ships Australia Wide
    Free postage is available on all orders over $199 when shipped via Australia Post, excluding power tools, cordless tools, and any individual items that weigh more than 10kg or have a volume equal to or greater than 10 litres.
  • 14 Days Free Returns
    • Item must be in new condition and not used.
    • Refunds will be processed once your item has arrived.
    • Return postage cost is the customer’s responsibility. If the product is faulty we cover the return cost as well.
    Read More
  • Manufacturer's Warranty
    All items are sold with Manufacturer's Warranty. Should your item be faulty within this time, your item will be repaired or replaced. Warranty only covers product defects, it does not apply to regular wear and misuse.
The safer, easier way to pay

Product Description

Description:
  • Discover the Toho Electric Chain Hoists at Discount Trader. These high-quality hoists are designed for efficient and safe lifting, offering a lightweight, compact build with a powerful motor. Perfect for various industrial applications, the hoists are built to comply with Australian standards and feature a durable alloy steel load chain, thermal prevention, and limit switches for safe operation. Available in multiple models with different capacities to meet your specific lifting needs
Features:
  • TOHO Electric Chain Hoists Single Phase
  • Load Limited
  • Thermal Prevention
  • Light weight, compact design with high efficiency motor
  • Pressed steel structure, high strength body
  • High tensile alloy steel top & bottom hooks
  • Grade 80 – 7.1mm Alloy Steel load chain
  • Limit switches fitted at top and bottom ends to prevent chain runout
  • 240V, 50Hz Single speed Motor 1200 Watts. (Single Phase)
  • Complies with ASNZS 1418.2 standard
  • Hoists can be re-chained to your required length (limits apply)
  • IP Rating Hoist: IP54 Control: IP65
  • Complies with Australian Standard AS1418.2
    • Optional TECH-RP Remote Pendant Control to suit TOHO Single Phase Electric Chain Hoist (Must be fitted, there is a 1.5hrs Labour Charge
Specifications:
  • Model TECH0103
  • Phase Single
  • Capacity ton 1
  • Standard Lift M 3
  • Running Test Load kN 12.5
  • Motor Power (kW) 1.2
  • No. of Chain 1
  • Dia of Chain mm 7.1
  • Lifting Speed (m/min) 6
  • Net Weight kg 60
  • Extra weight per metre of extra lift kg 1.1
UPC:
  • 9343662004681

Additional information

Weight 60 kg
Dimensions 60 × 50 × 40 cm
