Product Description

• Designed and tested by Macnaught to Retracta standards, the new C1 Series brings you a Retracta for smaller spaces. The new range of C1 Series Hose Reels are 35% smaller than the R3 Series and are ideal for small spaces and compact applications
• The Retracta C1 Hot and Cold Water Hose Reels are ideal for applications requiring high temperature water and/or pressure for wash down areas

• UV Stabilised & resistant poly case
• Australian designed
• 180° Swivel bracket
• 3 Position Reel swivel locking
• Powder coated steel bracket
• 35% smaller than the R3 Series
• High Temperature Hose rated to 80°C
• Bend Restrictor for increased durability
• 1.5 metre Feed Hose included

• Case Colour: Red
• Type: Hot / Cold Water
• Hose Inside Diameter: 1/2″ (12mm)
• Hose Length: 12 metres
• Hose Colour: Red
• Working Pressure: 300 psi
• Maximum Temperature: 80°C
• Feed Hose Inlet: 1/2″ BSP (F) Swivel
• Reel Inlet: 1/2″ BSPT (F)
• Hose Outlet: 1/2″ BSPT (M)
• Feed Hose Length: 1.5 metres

• Hose Reel – Hot / Cold Water
• Feed Hose – 1.5 metre

• 9317147754064
