Product Description

Benefits:

• Complete power control
• High accessibility / maneuverability
• Ergonomic
• Lightweight
• High durability
• High comfort
• Improved safety

Features:

• The best and the most adjustable power control for pneumatic tools
• 5, 10, 15, 20, 25, 30, 35, 40, 45, 50 and 100% of maximum torque
• Air Flex Mini integrated (Patented)
• Composite motor housing (4.25 lbs / 1.93 kg)
• Twin hammer mechanism
• Bumpers all over the tool
• Bi-material and bi-colour handle and trigger
• Friction ring socket retainer
• *Final torque must be applied manually using a calibrated torque wrench (please refer to the operator’s manual)

Specifications:

• Model CP7755 Air Flex Mini
• Part number 8941077551
• Actual air consumption 108 l/mn 3.9 cfm
• Air inlet thread size 1/4 “
• Blows per minute 1200
• Box dimensions 272x209x95 mm 10,7×8,2×3,7 “
• Clutch type Twin hammer
• Dimension A 63.5 mm 2 1/2 “
• Dimension B 55.4 mm 2.18 “
• European Directives 2006/42/EC (17/05/2006)
• European Sound standard EN ISO 15744
• European Standards EN ISO 11148-6:2013
• Free speed 7700 rpm
• Free speed air consumption 156 l/mn 5.6 cfm
• Handle type Pistol
• Height 205 mm 8.1 “
• Length 169 mm 6.65 “
• Maximum Torque (fwd) 1080 Nm 796 ft.lbs
• Maximum Torque (reverse) 1300 Nm 960 ft.lbs
• Min. hose size 10 mm 3/8 “
• Net weight 1.93 kg 4.25 lb
• Power/weight ratio 673 Nm/kg 225 ft.lb/lb
• Side to center 38 mm 1 1/2 “
• Socket retainer Friction ring
• Sound Power 105 db(A)
• Sound pressure 94 db(A)
• Sound uncertainty 3 db(A)
• Square drive 12.7 mm
• Vibration 8.5 m/s²
• Vibration ISO ISO-28927-2
• Vibration uncertainty (K) 3.4 m/s²
• Width 76 mm 3 “
• Working Torque Range (fwd) 80 – 575 Nm
